Description

Operating relative humidity (H-H) 10 – 90%
Package type Box
Storage temperature (T-T) -40 – 70 °C
Storage relative humidity (H-H) 5 – 90%
Product colour Black
Width 209 mm
Depth 126 mm
Height 26 mm
Operating temperature (T-T) 0 – 40 °C
Harmonized System (HS) code 85176990
Input current 2.43 A
Manual Yes
Networking standards IEEE 802.3af, IEEE 802.3at
Switch type Unmanaged
Basic switching RJ-45 Ethernet ports quantity 10
Basic switching RJ-45 Ethernet ports type Fast Ethernet (10/100)
10G support No
Copper ethernet cabling technology 10BASE-T, 100BASE-TX
Auto MDI/MDI-X Yes
Power over Ethernet (PoE) Yes
MAC address table 2000 entries
Store-and-forward Yes
Jumbo frames support
Jumbo frames 16000
Rack mounting No
Power supply included Yes
DC input voltage 53.5 V
Cable types supported Cat3, Cat4, Cat5, Cat5e
Auto-negotiation Yes
Switching capacity 7.6 Gbit/s
Forwarding rate 5.6544 Mpps
Power over Ethernet plus (PoE+) ports quantity 8
Total Power over Ethernet (PoE) budget 124 W
