Description

Certification CE, FCC, RoHS
Package width 336 mm
Package depth 528 mm
Package height 100 mm
Package weight 3.98 kg
Operating relative humidity (H-H) 10 – 90%
Storage temperature (T-T) -40 – 70 °C
Storage relative humidity (H-H) 5 – 90%
Form factor 1U
Cables included AC
AC input voltage 100 – 240 V
AC input frequency 50/60 Hz
Power source AC
Product colour Black
Width 440 mm
Depth 220 mm
Height 44 mm
Operating temperature (T-T) 0 – 50 °C
Harmonized System (HS) code 85176990
Security algorithms HTTPS, SNMP, SNMPv2, SNMPv3, SSH, SSH-2, SSL/TLS
User guide Yes
Management protocols SNMPv1/v2c/v3, SNTP
Power consumption (max)
Networking standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Web-based management Yes
Switch type Managed
Switch layer L2/L2+
Quality of Service (QoS) support Yes
Basic switching RJ-45 Ethernet ports quantity 24
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity 24
10G support No
Copper ethernet cabling technology 10BASE-T, 1000BASE-T
