Description

Certification CE, FCC, RoHS
Package width 250 mm
Package depth 400 mm
Package height 80 mm
Package weight 1.91 kg
Operating relative humidity (H-H) 10 – 90%
Storage temperature (T-T) -40 – 70 °C
Storage relative humidity (H-H) 5 – 90%
Cables included LAN (RJ-45)
Ethernet LAN data rates 10,100,1000 Mbit/s
Internal memory 2000 MB
Built-in processor Yes
Internal memory type DDR4
Flash memory 2 MB
Ethernet LAN (RJ-45) ports 2
Processor manufacturer ARM
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 1
Processor family ARM Cortex
Product colour Black
Width 294 mm
Depth 180 mm
Height 44 mm
Operating temperature (T-T)
Security algorithms SNMP, SSH
Input voltage 100 – 240 V
Power consumption (typical) 9 W
Quick installation guide Yes
LED indicators Yes
Power consumption (max) 14.8 W
Web-based management Yes
MAC address filtering Yes
Network address translation (NAT) Yes
Input frequency 50/60 Hz
