Description

600Mbps Powerline Speeds Ideal for HD Streaming

Using advanced Home Plug AV technology, TL-PA4010 KIT provides users with stable, high-speed data transfer rates of up to 600Mbps on a line length of up to 300 meters. With speed of up to 600Mbps,
TL-PA4010 KIT enables heavy-bandwidth applications like HD streaming, on-line gaming and large file downloading, turning your home into a robust and high-speed networking.

Miniature Design

With its new ultra-compact housing design, TL-PA4010 KIT is much smaller than TP-Link’s legacy mini 600Mbps powerline products. At just 28.5mm thick, it nearly blends completely in front of any power outlet.

Pair Button for Easy Network Security

Simply by pushing the Pair button on the adapters, users can set up a hassle-free Powerline network within minutes, complete with 128-bit AES encryption for network security and data protection.

It’s that simple!

1. Plug the adapter into the power outlet

2. Connect the device via the network cable to the adapter

3. Press the pair buttons—and you’re done!

Quantity per pack 2 pc(s)
Certification CE, FCC
Operating relative humidity (H-H) 10 – 90%
Storage temperature (T-T) -40 – 70 °C
Storage relative humidity (H-H) 5 – 90%
Ethernet LAN Yes
Wi-Fi No
Windows operating systems supported Yes
Mac operating systems supported Yes
Cables included LAN (RJ-45)
Ethernet LAN data rates 10,100 Mbit/s
Ethernet LAN (RJ-45) ports 1
Product colour White
Width 65 mm
Depth 52 mm
Height 28.5 mm
Operating temperature (T-T) 0 – 40 °C
Harmonized System (HS) code 85171800
Security algorithms 128-bit AES
Power consumption (standby) 0.88 W
Linux operating systems supported Yes
Power consumption (typical) 4.26 W
Quick installation guide
Plug and Play Yes
LED indicators Yes
Maximum data transfer rate 600 Mbit/s
Mac compatibility Yes
Networking standards IEEE 802.3, IEEE 802.3u
Copper ethernet cabling technology 10BASE-T, 100BASE-TX
Maximum operating distance 300 m
Modulation OFDM
Ethernet LAN interface type Fast Ethernet
Compliance certificates RoHS
