Description

Easy to Use PoE Switch with Innovative Design
Up To 250m Data and Power Transmission for Surveillance

High PoE Power Budget
TL-SL1218MP complies with the 802.3af/at PoE+ standard, supporting up to 30W power supply on each PoE port. The total high PoE power budget of up to 192W for the 16 PoE ports, making it ideal for small to medium business surveillance systems.

Up to 250m Transmission for Surveillance
TL-SL1218MP is a special designed PoE switch for IP surveillance applications. PoE switch makes surveillance installation simpler, safer and less expensive. With the extend mode, the PoE transmission distance reaches up to 250m* which makes it perfect for IP Camera deployment in large area coverage.

Video Quality Guaranteed
Priority mode guarantees the important data, such as video surveillance, delivered with the best priority passing the data fabric even when the traffic load is heavy. Hardware switch for easy configuration with no login required.

Certification CE, FCC, RoHS
Package width 250 mm
Package depth 528 mm
Package height 80 mm
Package weight 2.96 kg
Operating relative humidity (H-H) 10 – 90%
Package type Box
Storage temperature (T-T) -40 – 70 °C
Storage relative humidity (H-H) 5 – 90%
Form factor 1U
Cables included LAN (RJ-45)
AC input voltage 100 – 240 V
AC input frequency 50 – 60 Hz
Power source AC
Product colour Black
Width 440 mm
Depth 180 mm
Height 44 mm
Operating temperature (T-T) 0 – 40 °C
Harmonized System (HS) code 85176990
Manual Yes
LED indicators LAN, PoE, Status
Power consumption (max)
Networking standards IEEE 802.3af, IEEE 802.3at
Switch type Unmanaged
Basic switching RJ-45 Ethernet ports quantity 20
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity 2
10G support No
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T
Auto MDI/MDI-X Yes
Power over Ethernet (PoE) Yes
MAC address table 8000 entries
