Automatic Transfer Switch CNC 3P 220V 100A

Automatic transfer switch YCQ4-100R/3P 220V 100A


Features:
Automatic transfer switch 220VAC, 100A for emergency power supply system 50/60Hz, transfer time <50ms.&#x4;
The switch can also be operated manually.&#x4;
The switch complies requirements of low voltage switch gear and control gear specified by IEC 60947-6-1.&#x4;
Compact design, reliable switching, easy installation on a DIN rail.&#x4;
It is widely applicable in various occasions where continuous power failure is not allowed.&#x4;

&#x4;
Specifications:&#x4;
Voltage: AC220V.&#x4;
Current: 100A.&#x4;
Frequency: 50/60Hz.&#x4;
Number of contacts: 3.&#x4;
Insulation voltage (Ui): AC 690V.&#x4;
Rated voltage (Ue): AC 400V.&#x4;
Rated conditional short-circuit current: 50 kA.&#x4;
SCPD (fuse): RT16-00-63A.&#x4;
Rated impulse withstand voltage: 8 kV.&#x4;
Main voltage: AC 220V.&#x4;
Auxiliary circuit: AC 220V.&#x4;
Contact transfer time: <50 ms.&#x4;
Operating transfer time: <50ms.&#x4;
Return transfer time: <50ms.&#x4;
Off- time: <50ms.&#x4;
Installation: on a DIN rail.&#x4;
Dimensions: 124.8x100x76 mm.&#x4;
Mechanical life: 5000 times.&#x4;
Electrical life: 2000 times.&#x4;
Weight: 608g.&#x4;

&#x4;
Warranty: 24 months.&#x4;
