Description

Operating relative humidity (H-H) 0 – 95%
Storage temperature (T-T) -40 – 60 °C
USB 2.0 ports quantity 1
Scanner type 1D/2D
Connectivity technology Wired
Type Fixed bar code reader
Product colour Black
Width 98.2 mm
Depth 87.4 mm
Height 170 mm
Weight 340 g
Harmonized System (HS) code 84716070
Power consumption (standby) 0.45 W
Standard interfaces RS-232, USB, Keyboard wedge
Input voltage 5 V
Power consumption (typical) 2 W
LED indicators Yes
Power source type DC
Power consumption 400 mA
Sensor type Photo diode
Wavelength 620 nm
Light levels (direct sunlight) 0 – 100000 lx
2D (matrix & stacked) barcodes supported
Pitch reading angle 0 – 60°
Yaw reading angle 0 – 70°
Tilt reading angle 0 – 360°
Linear (1D) barcodes supported Code 39
Compliance certificates RoHS
