Description

Certification CE, FCC, RoHS
Operating relative humidity (H-H) 10 – 90%
Package type Box
Storage temperature (T-T) -40 – 70 °C
Storage relative humidity (H-H) 5 – 90%
Quick start guide Yes
Housing material Plastic
International Protection (IP) code IP20, IP40
Product colour Black
Width 90 mm
Depth 72 mm
Height 23 mm
Operating temperature (T-T) 0 – 40 °C
Harmonized System (HS) code 85176990
Input current 0.6 A
LED indicators Yes
Power consumption (max) 3.7 W
Networking standards IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Wall mountable Yes
Switch type Unmanaged
Basic switching RJ-45 Ethernet ports quantity 5
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
10G support
Flow control support Yes
Auto MDI/MDI-X Yes
Power over Ethernet (PoE) No
MAC address table 2000 entries
Store-and-forward Yes
Jumbo frames support Yes
Jumbo frames 16000
Packet buffer memory 1.5 MB
Rack mounting No
Power supply included Yes
