Description

Certification CE, FCC, RoHS
Operating relative humidity (H-H) 10 – 90%
Package type Box
Storage temperature (T-T) -40 – 70 °C
Storage relative humidity (H-H) 5 – 90%
AC input voltage 220 V
AC input frequency 50 Hz
Power source DC/PoE
Product colour Black
Width 158 mm
Depth 99 mm
Height 25 mm
Operating temperature (T-T) 0 – 40 °C
User guide Yes
Input current 1.31 A
LED indicators Yes
Power consumption (max) 71.61 W
Networking standards IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Switch type Unmanaged
Quality of Service (QoS) support Yes
Basic switching RJ-45 Ethernet ports quantity 8
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
10G support
Flow control support Yes
Auto MDI/MDI-X Yes
Power over Ethernet (PoE) Yes
MAC address table 4000 entries
Jumbo frames 16000
Power supply included Yes
DC input voltage 53.5 V
Heat dissipation 243.47 BTU/h
Cable types supported Cat3, Cat4, Cat5, Cat5e
Auto-negotiation Yes
