Description

Certification EN 60950-1 2ed + A11 + A1 + A12 + A2:2013, IEC 60950-1 2ed + A1 + A2, UL 60950-1, CAN/CSA-C22.2 No. 60950-1-07
IEC 62471
EN 55022 (Class B); EN 55032 (Class B)
EN 55024
EN 61000-3-2
EN 61000-3-3
47 CFR Part 15, Subpart B, Class B
ICES-003 Issue 6, Class B
Operating relative humidity (H-H) 5 – 95%
Storage temperature (T-T) -40 – 70 °C
Cables included Micro-USB
Scanner type 1D/2D
Connectivity technology Wired
Battery technology Lithium-Ion (Li-Ion)
Battery capacity 2400 mAh
International Protection (IP) code IP42
Sustainability certificates RoHS
Type Handheld bar code reader
Product colour Black
Width 66 mm
Depth 99 mm
Height 165 mm
Weight 161.6 g
Operating temperature (T-T) 0 – 50 °C
Harmonized System (HS) code 84716070
Standard interfaces USB, RS-232, RS-485, Keyboard wedge
LED indicators Yes
Power source type DC
Power consumption 250 mA
Battery life
AC adapter output voltage 5 V
Sensor type LED
Working distance 36.8 cm
Wavelength 645 nm
2D (matrix & stacked) barcodes supported Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
Pitch reading angle -65 – 65°
Yaw reading angle -65 – 65°
Motion tolerance (cm/s) 13
Tilt reading angle -65 – 65°
Linear (1D) barcodes supported Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, U.P.C.
