Description

Certification EN 50581:2012, RoHS 2011/65/EU (2015/863) – EN 50581:2012, IEC 63000, REACH 1907/2006, IEC 62368-1 2nd ed. EN 62368-1:2014/AC:2015, UL/IEC 60950-1, 2nd ed. CAN/CSA C22.2 No.60950-1, 2nd ed. IEC 62471:2006 (Ed.1.0), EN 62471:2008 (LED), FCC 47 CFR Part 15B, ICES-003, EN55032, EN55024, EN55035, VCCI, and SABS
Operating relative humidity (H-H) 5 – 95%
Storage temperature (T-T) -40 – 70 °C
Scanner type 1D/2D
Connectivity technology Wired
International Protection (IP) code IP52
Type Fixed bar code reader
Product colour Black
Width 86 mm
Depth 83 mm
Height 145 mm
Weight 318 g
Operating temperature (T-T) 0 – 50 °C
Harmonized System (HS) code 84716070
Standard interfaces RS-232, USB
Input voltage 5.5 V
Power source type RS-232, USB
Sensor type LED
Working distance 66 cm
Light levels (direct sunlight) 0 – 107700 lx
2D (matrix & stacked) barcodes supported Aztec Code, Composite Codes, Data Matrix, Dot Code A, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Pitch reading angle -60 – 60°
Linear (1D) barcodes supported
Optical sensor resolution (W x H) 1280 x 800 pixels
