Description

Certification EMC FCC Part 15 Class B, ICES 003 Class B,
IEC 60601-1-2 RoHS 2002/95/EEC
Operating relative humidity (H-H) 5 – 85%
Storage temperature (T-T) -40 – 70 °C
Cables included RS-232
Housing material Plastic
Battery technology Lithium Polymer (LiPo)
Bluetooth Yes
International Protection (IP) code IP54
Product colour Black
Weight 224 g
Cable length 1.8 m
Operating temperature (T-T) 0 – 50 °C
Harmonized System (HS) code 84716070
Standard interfaces RS-232, RS-485, USB, Keyboard wedge
Safety C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, UL 60950- 1 LED Class 1
Dimensions (WxDxH) 70 x 186 x 98 mm
Tilt angle range 0 – 35°
LED indicators Charging, Power
Light source LED
Wavelength 612 nm
Decoding standards UPC/EAN: UPC-A, UPC-E, UPC-E1, EAN-8/JAN
8, EAN-13/JAN 13, Bookland EAN, Bookland
ISBN Format, UCC Coupon Extended Code,
ISSN EAN
Code 128 Including GS1-128, ISBT
128, ISBT Concatenation, Code 39 including
Trioptic Code 39, Convert Code 39 to Code
32 (Italian Pharmacy Code), Code 39 Full
ASCII Conversion Code 93 Code 11 Matrix
2 of 5 Interleaved 2 of 5 (ITF) Discrete 2
of 5 (DTF) Codabar (NW – 7) MSI Chinese
2 of 5 IATA
Inverse 1D (except all GS1
DataBars) GS1 DataBar including GS1
DataBar-14, GS1 DataBar Limited, GS1
Light levels (direct sunlight) 0 – 108 lx
Pitch reading angle
Yaw reading angle 0 – 65°
Read rate (max) 547 reads/s
Tilt reading angle 0 – 45°
Maximum scan width 10 cm
Maximum range 6 m
Shockproof No
